Cubo 15

Hi Cubo, loving the simple design. Will this enclosure work with a Fane 15 collosus B? Regards, Ade.

Yes, it will.

It's a good driver for Cubo 15 Extended.

Best regards

Cubo

Finished my first cubo build some days ago. Went out great
But some how the board standard in sweden is smaller (1200x2440) so i had to use 1 + 1 board for the two 62x62 cuts.

But well finished the cubo played great

First test withe the 15"+1".
nerdsound.files.wordpress.com/2013/07/20130703-090742.jpg

Hi cubo, I'm thinking of building a couple of these will the Eminence Delta 15LF 4 Ohm Bass Drivers work in the cab? Regards Iain :0)

I have the delta 15lf's in mine and they move some serious air.

Hello Everyone I'm new to the forum and I'm about to start making Cubo15 not extended version. I was looking for a Eminence kappa 15lfa but the only speaker I can find in Lithuania is Delta 15lfa (Qts .47, Vas 221.6 liters / 7.8 cu. ft. other specs here www.newtone.lt/catalog.php?id=854 ). As I understand it is not the best choice for Cubo15 but anyways, can i use it? Will it 'work'? I will use Cubo15 mostly in my 18 m^2 room.

By the way, i have 400Wrms 4ohm / 250Wrms 8ohm amplifier, that's why 4 ohms are better for me.

Thank you for your time and answers. Vito.

Please email me the plans at siphosono@yahoo.com

Here we go:

www.part.lt/perziura/b2172fbfb0136ada2a027462c69bb216740.JPG
www.part.lt/perziura/33df43cde9adf36598549491939a763a738.JPG

It's not finished yet. Far from it. But OMG, Cubo15 is HUGE

www.part.lt/perziura/3cc346434bd78799d2adeb11d0946c6b519.JPG

Vito,

The photo's suggest you're building the Extended version of Cubo 15. For PA the dimensions are kinda compact but for a small room I can imagine it's kinda big. It will go kinda loud too.

If you think you'll need deeper bass, let me know.

Best regards

Cubo

To be honest, I need deep bass. I love deep bass dubstep and drum'n'bass, but this project is more like an experiment. I'm young student (University), who really likes loud music and heavy bass.
And about deeper bass, what would be Your suggestion?

By the way, I made ~100 liters ported box with Cerwin vega 12'' subwoofer for my friend and that was really really deep and powerful in my room. Any possibilities for Cubo15 run like that?

Thank You for Your answer.
