- Posts: 15
- Thank you received: 0
MTH-30
- goodgroove
-
- Offline
- New Member
-
Less
More
12 years 10 months ago #15500
by goodgroove
Replied by goodgroove on topic MTH-30
Are the JBL 2206 and JBL 2204 speakers suitable for this cab as I have a number of these spare?Thanks
Please Log in or Create an account to join the conversation.
- Truckinve
-
- Offline
- New Member
-
Less
More
- Posts: 2
- Thank you received: 0
12 years 10 months ago #15765
by Truckinve
Replied by Truckinve on topic MTH-30
We just build a MTH30, the only thing that is not finished is the paint , we will go for a latex one as this box is going to be on a fixed location on a pub and I need a different color than duratex.
Initial impressions:
-First and most important: This will be a very good first time build or if you have been a looong time out of woodworking smiley20 .
- For the size its very loud we were pretty amazed when you find the right spot and in this bar was a real pain.
- Clean bass this little beast will outperform most of the installs around the area.
- Only thing to check is be careful when using the PD Sb30 driver, if your using the 8 concealed holes be careful when punching them, use a big needle or whatever sharp object as you can damage the surround of the driver.
- And for gods sake dont use DM panel for mobile installs. We used it for the fixed but we dont want anyone moving this thinking is a chair.... :think:
The install consist in 8 LD coaxial boxes around the pub, sound was OK (after EQ) whitout the sub but the amps were working pretty hard at the most populated hours, so we decide for this sub and what a difference!, after running all the system thru a DSP processor and after test the MTH30, we were like :shock: , the amps were working at 20 or 30%?¿ hitting inside 80db (local law), and the SQ was very very nice.
Oh and some pics soon!
Big thanks to the designer and the Freespeakerplans users
Initial impressions:
-First and most important: This will be a very good first time build or if you have been a looong time out of woodworking smiley20 .
- For the size its very loud we were pretty amazed when you find the right spot and in this bar was a real pain.
- Clean bass this little beast will outperform most of the installs around the area.
- Only thing to check is be careful when using the PD Sb30 driver, if your using the 8 concealed holes be careful when punching them, use a big needle or whatever sharp object as you can damage the surround of the driver.
- And for gods sake dont use DM panel for mobile installs. We used it for the fixed but we dont want anyone moving this thinking is a chair.... :think:
The install consist in 8 LD coaxial boxes around the pub, sound was OK (after EQ) whitout the sub but the amps were working pretty hard at the most populated hours, so we decide for this sub and what a difference!, after running all the system thru a DSP processor and after test the MTH30, we were like :shock: , the amps were working at 20 or 30%?¿ hitting inside 80db (local law), and the SQ was very very nice.
Oh and some pics soon!
Big thanks to the designer and the Freespeakerplans users
![:-D :-D](/bigsmile.gif)
Please Log in or Create an account to join the conversation.
- bitzo
-
- Offline
- Platinum Member
-
Less
More
- Posts: 637
- Thank you received: 1
12 years 8 months ago #16274
by bitzo
Replied by bitzo on topic MTH-30
Hi all,
I simmed the cab loaded with rcf mb12g301. I took care of the negative expansion created by the driver protruded into the horn mouth.
[attachment=1:380a5bpo]<!-- ia1 -->mth30sim.jpg<!-- ia1 -->[/attachment:380a5bpo]
seems that a kick isn't needed but don't drop so low, it's a 2pi placement btw.
So.... I put some dogleg like in the apache sub, loaded with same driver
[attachment=0:380a5bpo]<!-- ia0 -->apache12sim.jpg<!-- ia0 -->[/attachment:380a5bpo]
now it drops 10hz lower and is smaller. -10 cm tall -5 cm deep.
now it needs a proper kick section
I simmed the cab loaded with rcf mb12g301. I took care of the negative expansion created by the driver protruded into the horn mouth.
[attachment=1:380a5bpo]<!-- ia1 -->mth30sim.jpg<!-- ia1 -->[/attachment:380a5bpo]
seems that a kick isn't needed but don't drop so low, it's a 2pi placement btw.
So.... I put some dogleg like in the apache sub, loaded with same driver
[attachment=0:380a5bpo]<!-- ia0 -->apache12sim.jpg<!-- ia0 -->[/attachment:380a5bpo]
now it drops 10hz lower and is smaller. -10 cm tall -5 cm deep.
now it needs a proper kick section
![:) :)](/media/kunena/emoticons/8.png)
Attachments:
Please Log in or Create an account to join the conversation.
- t.geessounds
-
- Offline
- Elite Member
-
Less
More
- Posts: 172
- Thank you received: 4
11 years 3 months ago #20119
by t.geessounds
Replied by t.geessounds on topic Re: MTH-30
have anyone have a modify plan for the mth-30 in 18mm plywood where an at i cant find 15mm
thanks
thanks
Please Log in or Create an account to join the conversation.
- anthonytutton
-
- Offline
- New Member
-
Less
More
- Posts: 10
- Thank you received: 2
10 years 11 months ago #20634
by anthonytutton
Replied by anthonytutton on topic MTH-30
Hi, I too would like to use 18mm ply, can anyone help with the measurements?
The following user(s) said Thank You: t.geessounds
Please Log in or Create an account to join the conversation.
- t.geessounds
-
- Offline
- Elite Member
-
Less
More
- Posts: 172
- Thank you received: 4
10 years 9 months ago #20841
by t.geessounds
Replied by t.geessounds on topic MTH-30
anybody??
Please Log in or Create an account to join the conversation.
- Vanheeske
-
- Offline
- New Member
-
Less
More
- Posts: 2
- Thank you received: 0
10 years 5 months ago #21484
by Vanheeske
Replied by Vanheeske on topic MTH-30
Hello,
I'm also looking for 18 mm plans, c'mon anyone?
I'm also looking for 18 mm plans, c'mon anyone?
Please Log in or Create an account to join the conversation.
- colinuk
-
- Offline
- New Member
-
Less
More
- Posts: 1
- Thank you received: 0
10 years 1 month ago #21928
by colinuk
Replied by colinuk on topic MTH-30
I have drawn this up in Sketchup using 18mm board. If anyone is interested the file is in the 3d warehouse. I have not simulated, built or tested it. If you do, please share the results.
Please Log in or Create an account to join the conversation.
- t.geessounds
-
- Offline
- Elite Member
-
Less
More
- Posts: 172
- Thank you received: 4
10 years 1 month ago #21931
by t.geessounds
Replied by t.geessounds on topic MTH-30
am up for the building test
my email is
jegeban@yahoo.com
thanks
my email is
jegeban@yahoo.com
thanks
Please Log in or Create an account to join the conversation.
- fellamelad
-
- Offline
- New Member
-
Less
More
- Posts: 2
- Thank you received: 0
9 years 10 months ago #22166
by fellamelad
Replied by fellamelad on topic MTH-30
Hi i have built an MTH-30 using 18mm MDF and just sized up the cab by working out the internal measurements and working outwards if you know what i mean , in other words the whole cab is 6mm wider 12mm deeper and 9mm higher , i think that was right but i could just measure up the cab .
