4th order box help needed
- Jaythelocksmith
-

				 Topic Author Topic Author
- Offline
- New Member
-

        Less
        More






                8 years 4 months ago                #23979
        by Jaythelocksmith











        4th order box help needed was created by Jaythelocksmith

        Hi is there anyone here can help with box design?
I'm looking to make a 4th order box 110cm wide x 148cm long, question is how high, what size chambers and port size to tune it to 33Hz?
I will be using 25mm ply and 2x 15" L7's if that helps
Tia
    I'm looking to make a 4th order box 110cm wide x 148cm long, question is how high, what size chambers and port size to tune it to 33Hz?
I will be using 25mm ply and 2x 15" L7's if that helps
Tia
Please Log in or Create an account to join the conversation.
- Cubo15
-


- Offline
- Platinum Member
-

        Less
        More



        - Posts: 927
- Thank you received: 132


                8 years 4 months ago                #23980
        by Cubo15











        Replied by Cubo15 on topic 4th order box help needed

        I think you should try diyaudio.com (subwoofer or caraudio forum) for full help. They're probably gonna ask for the Thiel Small parameters, so be prepared. Coincidentally, with a 4th order BP, the low end is tuned by a closed chamber (without ports), the ports tune the upper part of the spectrum (around 80 - 100 Hz) and a port surface area that's 1/4 of the drivers combined Sd is a good starting point.
Best regards Cubo
    Best regards Cubo
