Speakon to amplifier

Klinke
Topic Author
Offline
New Member

9 years 8 months ago #22650 by Klinke

Speakon to amplifier was created by Klinke

Hey FSP.

I got 2 of these speakers: www.disconetto.dk/shop/pa-hoejttaler-pab-112mk2-20995p.html
This amplifier: www.pioneer.eu/eur/products/25/29/182/GM-D8604/specs.html

And i got 2 speakon cables with 4 wires, black, white, yellow and red.

I assume that plugin to the speaker is the original connector on the cable, but how do I connect the cable to the amplifier?

Thank you.

Please Log in or Create an account to join the conversation.

bee
Offline
Platinum Member

9 years 8 months ago - 9 years 8 months ago #22651 by bee

Replied by bee on topic Speakon to amplifier

the amp you have is a car audio amp.... not a pa amp....

you would wire it positive on amp to +1 on speakon, negative on amp to -1 on speakon. only two wires are needed...

www.elements-audio.com

www.facebook.com/pages/Element-Audio/187065531315529?ref=hl

Last edit: 9 years 8 months ago by bee. Reason: typo

The following user(s) said Thank You: Klinke
