Cubo 18
- oskarociak
-
- Offline
- New Member
-
Less
More
1 year 6 months ago #25031
by oskarociak
Replied by oskarociak on topic Cubo 18
Hi
would it be a good idea to put the Eminence Sigma Pro-18A-2 speaker in the cubo18 box?
would it be a good idea to put the Eminence Sigma Pro-18A-2 speaker in the cubo18 box?
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
1 year 6 months ago #25032
by Cubo15
Replied by Cubo15 on topic Cubo 18
The Sigma Pro-18A-2 is a good speaker for Cubo 18 Standard, the main two drawbacks are the lowish Xmax and the 3" voice coil. Do you use these already or are you planning to buy them?
Please Log in or Create an account to join the conversation.
- oskarociak
-
- Offline
- New Member
-
Less
More
- Posts: 4
- Thank you received: 0
1 year 6 months ago #25034
by oskarociak
Replied by oskarociak on topic Cubo 18
Thanks
I have speaker in bad reflex (90L)
I have speaker in bad reflex (90L)
Please Log in or Create an account to join the conversation.
- DevFelix
-
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
1 year 6 months ago #25035
by DevFelix
Replied by DevFelix on topic Cubo 18
Hey Cubo,
great design!
The Gain SPL Diagram clearly shows that the case works very well together with the V18-1000.
Unfortunately, it is only available to a limited extent in my region. Is there a good alternative?
Greetings
great design!
The Gain SPL Diagram clearly shows that the case works very well together with the V18-1000.
Unfortunately, it is only available to a limited extent in my region. Is there a good alternative?
Greetings
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
1 year 6 months ago - 1 year 6 months ago #25037
by Cubo15
Replied by Cubo15 on topic Cubo 18
@oskarociak: If you already have it you might as well use it, it should take similar power as in the reflex but will have more output. It does benefit from a high pass filter around 35 - 40 Hz, due to the limited Xmax.
@DevFelix: Drivers like the V18-1000 are not very common and tend to be expensive as well (large voice coil and low Qts do that to any driver). The V18-1000 was basically a cheaper alternative for the PD.1850. Non- neodymium drivers like that are a b!tch to move though, you need to be in great shape to not mind.
Where are you located?
@DevFelix: Drivers like the V18-1000 are not very common and tend to be expensive as well (large voice coil and low Qts do that to any driver). The V18-1000 was basically a cheaper alternative for the PD.1850. Non- neodymium drivers like that are a b!tch to move though, you need to be in great shape to not mind.
Where are you located?
Last edit: 1 year 6 months ago by Cubo15.
Please Log in or Create an account to join the conversation.
- DevFelix
-
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
1 year 6 months ago #25038
by DevFelix
Replied by DevFelix on topic Cubo 18
I understand. It was clear to me that such non-neodymium drivers would make transport considerably more difficult. However, I first wanted to weigh what is possible without paying attention to the weight.
Are there drivers that deliver similarly good results, and maybe even be neodymium-loaded in the best case?
Im located in Germany.
Are there drivers that deliver similarly good results, and maybe even be neodymium-loaded in the best case?
Im located in Germany.
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
1 year 6 months ago #25039
by Cubo15
Replied by Cubo15 on topic Cubo 18
As the V18-1000 is based on the PD.1850/1, the current PD.1850/3 is probably the closest in weight and performance. The 18DS115 is neodymium and can be seen as a step up in performance but like the 18IPAL, it will need amplifiers in excess of 2000 - 3000 W per driver to really showcase their difference. Up to about 1000 - 1500 W per driver of amplifier power I would consider neodymium drivers like the LF18N401, 18NLW9400 or the 18NW100. Their Qts is a bit higher to be considered true analogs of the V18-1000 but it's still in the right ball park. While they "only" have 4" voice coils, they're of a newer generation and typically weigh less than 10 kg.
Please Log in or Create an account to join the conversation.
- yNicoDev
-
- Offline
- New Member
-
Less
More
- Posts: 1
- Thank you received: 0
1 year 4 months ago #25040
by yNicoDev
Replied by yNicoDev on topic Cubo 18
Hello
Would it be a good idea to put the PDN.18BR40 speaker in the cubo18 box? I have two lying around at home...
If so, extended or normal version? I seem to remember that I quickly reached the xmax in BR
Would it be a good idea to put the PDN.18BR40 speaker in the cubo18 box? I have two lying around at home...
If so, extended or normal version? I seem to remember that I quickly reached the xmax in BR
Please Log in or Create an account to join the conversation.
- Zambrotta
-
- Offline
- New Member
-
Less
More
- Posts: 14
- Thank you received: 0
3 months 1 week ago #25072
by Zambrotta
Replied by Zambrotta on topic Cubo 18
Hello Cubo how are you. I have a question is the Cubo 18 suitable for small to medium sized events in a scenario wherby i will use it with a mid high cabinet directly on top of the cubo 18 using a speaker pole.
Please Log in or Create an account to join the conversation.
- Zambrotta
-
- Offline
- New Member
-
Less
More
- Posts: 14
- Thank you received: 0
3 months 1 week ago #25073
by Zambrotta
Replied by Zambrotta on topic Cubo 18
Another question there is a wave of paraflex subwoofers around everyone going paflex from your expertise mr Cubo how good are they
Please Log in or Create an account to join the conversation.
