Cubo12 full range
- GG_
-
Topic Author
- Offline
- New Member
-
Less
More
7 years 3 months ago #23956
by GG_
Cubo12 full range was created by GG_
Hi everybody, hi Mr.Cubo, I just made 4 nice Cubo 12, thanks a lot for share your plans, really good sound, I load them with Fane 12-500lf cheap and solid, but now I tell you my question, because I need something on top...
I have two Fane 12-250tc full range speaker, with triple cone, now they are in two scoop bins and they are ok, nice sound and not so bad bass, but scoops are too big, even 12", so I think about your designs with kiss principles... I'm thinking about a cubo-size speaker but good for this fane 12-250tc...
I already searched in the forum about this fane full range speaker but I didn't find an answer good for my situation, so I kindly ask if someone from this forum can help me with this project.
Luigi
(in picture is my sound system)
I have two Fane 12-250tc full range speaker, with triple cone, now they are in two scoop bins and they are ok, nice sound and not so bad bass, but scoops are too big, even 12", so I think about your designs with kiss principles... I'm thinking about a cubo-size speaker but good for this fane 12-250tc...
I already searched in the forum about this fane full range speaker but I didn't find an answer good for my situation, so I kindly ask if someone from this forum can help me with this project.
Luigi
(in picture is my sound system)
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
7 years 3 months ago #23960
by Cubo15
Replied by Cubo15 on topic Cubo12 full range
The Fane 12-250tc is really made for one thing and that is a full range cabinet, with not enough Xmax to do much, if any bass-reinforcement on high levels. KISS in this case would mean it's put it in a closed cabinet, of about 100 litres external (so pretty much the same volume as a Cubo 12). Crossed around 100 Hz, to do mid-high for close range listening.
I can give you some more accurate internal volume if you'd like.
Best regards Cubo
I can give you some more accurate internal volume if you'd like.
Best regards Cubo
The following user(s) said Thank You: GG_
Please Log in or Create an account to join the conversation.
- GG_
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 8
- Thank you received: 1
7 years 3 months ago #23961
by GG_
Replied by GG_ on topic Cubo12 full range
yes Mr.Cubo, thank you for your fast reply, this is what I 'm looking for, a cabinet with approx. same sizes of cubo12 but good for this kind of speaker, so I can play 4 cubo12 with fane 12-500lf for bass and this 2 fane 12-250tc on top for all the rest of frequencies, a really small sound system, total 6 speakers and 2500 watt, easy to transfer everywhere just in a normal car. thank you for your help
best regards
Luigi
best regards
Luigi
Please Log in or Create an account to join the conversation.
- Cubo15
-
- Offline
- Platinum Member
-
Less
More
- Posts: 916
- Thank you received: 131
7 years 2 months ago #23966
by Cubo15
Replied by Cubo15 on topic Cubo12 full range
A cabinet of internal 57 litres, made from 15 mm sheet, with the front of the baffle 15 mm behind the front of the cabinet. External 45 cm wide, 57 cm high and 30 cm deep. If you use dampening inside the cabinet on all walls (recommended), you can make the cabinet 26,5 cm deep (instead of 30 cm).
Best regards
Cubo
Best regards
Cubo
The following user(s) said Thank You: GG_
Please Log in or Create an account to join the conversation.
- citcut
-
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
7 years 2 months ago #23969
by citcut
Replied by citcut on topic Re:Cubo12 full range
Any construction plan and cut sheet for this cubo 12 full range?
Sent from my ASUS_X00DDB using Tapatalk
Sent from my ASUS_X00DDB using Tapatalk
Please Log in or Create an account to join the conversation.
- citcut
-
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
7 years 2 months ago #23970
by citcut
Replied by citcut on topic Re:Cubo12 full range
Any construction plan and cut sheet for this cubo 12 full range?
Sent from my ASUS_X00DDB using Tapatalk
Sent from my ASUS_X00DDB using Tapatalk
Please Log in or Create an account to join the conversation.
- GG_
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 8
- Thank you received: 1
7 years 2 months ago #23972
by GG_
Replied by GG_ on topic Re:Cubo12 full range
you can made 2 box from a single 122x244, sorry if cut list is handmade
Please Log in or Create an account to join the conversation.
- citcut
-
- Offline
- New Member
-
Less
More
- Posts: 3
- Thank you received: 0
7 years 2 months ago #23973
by citcut
Replied by citcut on topic Re:Cubo12 full range
May I see the finished one?
Sent from my ASUS_X00DDB using Tapatalk
Sent from my ASUS_X00DDB using Tapatalk
Please Log in or Create an account to join the conversation.
- GG_
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 8
- Thank you received: 1
7 years 2 months ago #23974
by GG_
Replied by GG_ on topic Cubo12 full range
almost done
![:) :)](/media/kunena/emoticons/8.png)
Please Log in or Create an account to join the conversation.
- GG_
-
Topic Author
- Offline
- New Member
-
Less
More
- Posts: 8
- Thank you received: 1
7 years 2 months ago - 7 years 2 months ago #23988
by GG_
Replied by GG_ on topic Cubo12 full range
nice sound, 250watt rms, easy to transport, thank you Mr. Cubo for your help in this project
Last edit: 7 years 2 months ago by GG_.
