Cubo Sub

More
9 years 7 months ago #22597 by Discosucks
Replied by Discosucks on topic Cubo Sub
Wow only seeing these for the first time now!

they look proper neat! and all from one sheet!!!

Please Log in or Create an account to join the conversation.

More
9 years 7 months ago #22599 by Kvdb013
Replied by Kvdb013 on topic Cubo Sub
3 sheets -2 subs ;)

Please Log in or Create an account to join the conversation.

More
9 years 4 months ago #22766 by valmiki77
Replied by valmiki77 on topic Cubo Sub
Cubo, do you think these prv's will cut it in the cubo sub?
www.parts-express.com/prv-audio-18sw3000...ofer-8-ohm--294-2755
How low do you think I'll get with them? I already have the subs in a Yorkie ls608 enclosure but I need to go lower than 50hz. These subs roll steep below 50. Help!

Please Log in or Create an account to join the conversation.

More
9 years 4 months ago #22769 by t.geessounds
Replied by t.geessounds on topic Cubo Sub

valmiki77 wrote: Cubo, do you think these prv's will cut it in the cubo sub?
www.parts-express.com/prv-audio-18sw3000...ofer-8-ohm--294-2755
How low do you think I'll get with them? I already have the subs in a Yorkie ls608 enclosure but I need to go lower than 50hz. These subs roll steep below 50. Help!


those speakers only have a xmax of 8mm and the spec some how always not right for that price u can get the 18sound lw2400 that work well in the cubo sub..

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
9 years 4 months ago #22773 by Cubo15
Replied by Cubo15 on topic Cubo Sub
@Valmiki77: I would use the 18SW3000 in Cubo Sub with the magnet inside the chamber. That way it will start to roll off somewhere around 35 Hz and be usable from 30 Hz and up. With the magnet inside the horn it will go a few Hz lower but at the cost of maximum output.

You could also build Cubo 18 Extended, which will be somewhere inbetween the Yorkie and Cubo Sub.

@t.geessounds: IIRC Valmiki77 already bought the 18SW3000 a few years back.

Best regards

Cubo

Please Log in or Create an account to join the conversation.

More
9 years 3 months ago #22823 by t.geessounds
Replied by t.geessounds on topic Cubo Sub
would the 18sound 18nlw9601 work well in the cubo sub??

Please Log in or Create an account to join the conversation.

More
9 years 3 months ago #22833 by geritass
Replied by geritass on topic Cubo Sub
Hi, Cubo. may you recommend me the best subwoofer speaker for the CUBO SUB, and the CUBO 18 than reach the maximum Low frecuencie and maximum SPL (18sound, RCf, B&C, faitalpro)
thanks

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
9 years 3 months ago - 9 years 3 months ago #22836 by Cubo15
Replied by Cubo15 on topic Cubo Sub
@T.geessounds: The 18NLW9601 is not the most efficient subwoofer, I would only recommend it if you have at least a solid 1500 W or more to feed it. In a Cubo 18 Extended it's about 2 dB less efficient than a Cubo 15 loaded with the Eminence Kappa 15LF. At full power it can rival with a double Cubo 15 loaded with the Kappa 15LF. If I had a 2000 - 2500 W amplifier it would be one of the few 18"driver choices for Cubo Sub.

@Geritass:

RCF: Cubo Sub: LF18X451 Cubo Sub and Cubo 18 LF18N451, LF18N401
18Sound: Cubo Sub and Cubo 18: 18NLW9601 (see above), 18NLW9000 Cubo 18: 18NLW9400
B&C: Cubo Sub: 18SW115, 18SW100 Cubo Sub and Cubo 18: 18NW100
Faital Pro: Cubo Sub: 18XL1600, Cubo Sub and Cubo 18: 18HP1020

All drivers will have similar low frequency response, maximum SPL will be mostly power related below 80 Hz. Choose the one with the biggest coil, for either Cubo Sub or Cubo 18, with most Xmax for Cubo Sub

Best regards

Cubo
Last edit: 9 years 3 months ago by Cubo15.

Please Log in or Create an account to join the conversation.

More
9 years 1 month ago #22949 by tj6006
Replied by tj6006 on topic Cubo Sub
Hi!

My first post here on the forum :)

I have a spare speaker, and i would like to use it for CUBO SUB.

Here is what I have:

Woofer Diameter 18" / 45.72 cm
Coil Diameter 3"
Fs 29 Hz
Qts 0.454
Qes 0.506
Qms 4.382
Vas 136.5 L
2-Way Suspension Travel 80mm
Cutout Diameter 16.75"
Mounting Depth 9.5"

Would this speaker work well?

I plan to use it as subwoofer, from 30-120hz (maybe just 30-90hz), driven with fp10.000.

Thanks a lot!

Please Log in or Create an account to join the conversation.

  • Cubo15
  • Topic Author
  • Offline
  • Platinum Member
  • Platinum Member
More
9 years 1 month ago #22970 by Cubo15
Replied by Cubo15 on topic Cubo Sub
The DD3500 series is primarily designed for use in small (automotive) enclosures. The 18" could be used in Cubo Sub but I would definitely try to mount it with the magnet in the chamber first for PA applications. Be sure you have at least about half an inch between the rear of the magnet and the inner part of the horn.

I think 30 -90 Hz is a safe bet, high excursion and a high crossover point usually are rivalry points for a driver.

Best regards

Cubo

Please Log in or Create an account to join the conversation.
