J-bin reflex horn

Thawach wrote: guys the pics about a&j brand in thailand built und measure the 18 J-bin cab. he use the base on RCF esw1080 but change the dimension for the drv. the prototype of this cab. i thing the cab will built in china factory in the next time. the product will sell in thailand. the old cab of this brand they use china factory make at all. as the same the PA amp made in china.

Greetings; When measureing a sub its best to have the microphone on the ground on a large flat surface around the size of a sheet of plywood etc. Also have the microphone at least 10 feet away from the sub with the microphone pointed 90 degrees from the box. The pressure from the port will give incorrect results when you measure too close to the box.
The poor phase response and the dip in COH is a standard issue that may come up when measuring a sub with the microphone off the ground. A phase response in the attached photo will give you a better idea as to what you may be looking for. You can see near 0 COH problems, The phase trace is near 0 degrees at the crossover point and other than the High cut filters and Low cut fiters there is no phase "wraps" in the bandwith of the sub.

Doug

how about the Eminence Omega Pro-18A

dookietwo2 wrote:

Thawach wrote: guys the pics about a&j brand in thailand built und measure the 18 J-bin cab. he use the base on RCF esw1080 but change the dimension for the drv. the prototype of this cab. i thing the cab will built in china factory in the next time. the product will sell in thailand. the old cab of this brand they use china factory make at all. as the same the PA amp made in china.

Greetings; When measureing a sub its best to have the microphone on the ground on a large flat surface around the size of a sheet of plywood etc. Also have the microphone at least 10 feet away from the sub with the microphone pointed 90 degrees from the box. The pressure from the port will give incorrect results when you measure too close to the box.
The poor phase response and the dip in COH is a standard issue that may come up when measuring a sub with the microphone off the ground. A phase response in the attached photo will give you a better idea as to what you may be looking for. You can see near 0 COH problems, The phase trace is near 0 degrees at the crossover point and other than the High cut filters and Low cut fiters there is no phase "wraps" in the bandwith of the sub.

Doug

thanks dookietwo2 for suggestion. the cab i didnt measure by myself but i got it from aj brand show me.

t.geessounds wrote: how about the Eminence Omega Pro-18A

hi tg dont sure will install with this box but the sim i will post next time.

Hi, everyone!
Firstly I want to say that I don`t have a lot of experience in building and modelling sub cabs.
I`ve got some questions about 15" J-bin :
1) can I load such drv in this cab
TS parameters of the drv
Fs 42,3 Hz
Vas 77 L
Qts 0,43
Qes 0,45
Qms 8,4
Re 6,2 Оhm
Bl 23,2 Тм
Sd 755 sм²
Mms 147 g
Xmax 8,5 мм
L 3,2 mGn
h 1,23 %

35 - 500 Hz
8 ohm
1000w RMS

2) does this cab sound good playing DNB and Dubstep ???
thanks

sorry i never hv listened the DNB and Dubstep music before. i only know morlum lao hip-hop. so thta i dont sure for the DNB and Dubstep music . what is the brand of ur drv?

This is Ukrainian driver MAG 1501
www.audiosila.com/product/dinamik-mag-m1501/

D-monk u come from the Ukrain. i just hv known the Ukrainian drv. my daughter learn in china and she also speak Ukrain lang because she hv many friens from Ukrain in her room. ur driver i sim the graph below.

Thanks a lot!!!
It`s a nice surprise for me that you have known Ukrainian drivers!
Thank you for simulation for my drv, a hope I`ll start building at the weekend.

may be the new j-bin guys
